Vitalograph ALPHA Touch

The new generation Vitalograph ALPHA Touch is an easy to use, lightweight desktop spirometer that offers the benefits of portability, data integration and a built in printer. The ALPHA Touch features a precise and robust Fleisch pneumotachograph and a simple icon driven menu, plus a large, high resolution colour touch-screen and storage capacity for 10,000 subjects.
Manual entry of subject data is optional as ALPHA Touch automatically copies all subject data from Spirotrac – saving time and eliminating data entry errors.

Downlaod: Alpha TOUCH

Category: Physiology

Reviews (0)

Reviews

There are no reviews yet.

Be the first to review “Vitalograph ALPHA Touch”

Related products

Vitalograph ALPHA

Product: ALPHA Spirometer Model No: 6000 Size: 300 x 250 x 75mm Weight: 2kg net Parameters Measured: Varies by country variant Operating Temperature Range: ATS/ERS Limits: 17 – 37°C Design Limits: 10 – 40°C Voltage/Frequency: 110-250V~50/60Hz Flow Detection Principle: Fleisch type pneumotachograph Volume Detection: Flow integration sampling @ 100Hz Accuracy when Operated in Operating Temperature Range Conditions: Flow +/- from 10% to 5% Max flow rate +/-16L/s Min flow rate +/-0.02L/s Volume Accuracy: Better than +/-3% Maximum Displayed Volume: 10 L
Maximum Test Duration: 90 seconds Flow Impedance: <0.1kPa/L/s @ 14L/s Complies with ATS/ERS 2005 Printer: Thermal Performance Standards: ATS/ERS 2005 & ISO 26782:2009, ISO 23747:2007 Safety Standards: IEC 60601-1:2005 Medical Safety Standard: Medical Devices Directive 93/42/EEC as amended Designed & Manufactured Under: ISO 13485:2003, FDA 21CFR820, CMDR Communications: USB and Compact Flash
Download: ALPHA

Read more
Stethograph
The Stethograph is designed for recording human respiratory movement with a recording device such as a tambour or transducer.

The corrugated rubber tubing is 200mm (8 inch) long and 35mm (13/8 inch) diameter. A nickel-plated chain 850mm (34 inch long, is secured at one end of the Stethograph, and may be secured at any point to a hook at the opposite end. In this manner the Stethograph may be placed in a convenient, yet unyielding, way on the subject.

At one end of the Stethograph is riffled tube with an inside diameter of 3mm (1/8 inch), for connection to the tambour or the recoding device,

Stethograph

Stethograph and Tambour :

The combination of these two items is used to record respiratory patterns, i.e rate, rhythm and amplitude during conditions :During * Talking

* Swallowing

* Speaking

* After Walking

* Breath Holding

* Hyper Ventilation

Use the Frontal Writing Point with Aluminum Stem and fixed the Kymograph Speed No: 3. and normal respiration, using two sets it is also possible to study chest and abdominal movements simultaneously under a variety of circumstance. (See drawing below).

Download:Stethograph Manual AWS
Read more
Kymograph Accessories

Frog Board

To prevent warping, this (8×5) inch, Frog Board is made of a wooden (3/4 inch) thick. A Clamp and locking screw are mounted on the side 9.5mm (3/8 inch) diameter rod (not supplied)

Download:kymograph Acce

Read more
Student Kymograph 2

The AWS Student Kymograph is very reliable instrument for use in the study of physiology, pharmacology and Biological Science. There are two instrument model available and each is provided with a series of advance features. The instrument are available with or without stimulator. There is a range of accessories two suit most applications. Illustrated with the kymograph below is one suggested kit or assembly of the more popular accessories.

Download:Student Kymograph (2)

Read more
