Student Spirometer

Related products

•

  Spirometer

  Add to wishlist

  Quick view

  Read more
•

  Ergometer

  This AWS figure ergo-meter is ideal for the study of human muscle fatigue. It can be used to record frequency, duration, speed of pull and relaxation curves. A pistol grip carries a trigger that operates against and adjustable spring tensioning device. The pivot point of the trigger holds and adjustable rod, to which a nylon line is secured. This line is wrapped around and adjustable pulley and anchored to a small spring at the top of an upright. A holder on pulley carries an ink writing stylus, which receives ink from a small reservoir. The height of the holder is adjustable. The aluminum base is 125mm (5 inch) wide and 500mm (20 inch) long which is sufficient to support the entire forearm when the hand is holding the pistol grip. A holder on pulley carries an ink writing stylus, which receives ink from a small reservoir. The height of the holder is adjustable. The aluminum base is 125mm (5 inch) wide and 500mm (20 inch) long which is sufficient to support the entire forearm when the hand is holding the pistol grip. Two uprights, which are adjustable for width, are mounted on the base to support and study the wrist. The instrument may be rapidly adopted for the use with a transducer.

  Download:Ergometer

  Add to wishlist

  Quick view

  Read more
•

  Vitalograph ALPHA

  Product: ALPHA Spirometer Model No: 6000 Size: 300 x 250 x 75mm Weight: 2kg net Parameters Measured: Varies by country variant Operating Temperature Range: ATS/ERS Limits: 17 – 37°C Design Limits: 10 – 40°C Voltage/Frequency: 110-250V~50/60Hz Flow Detection Principle: Fleisch type pneumotachograph Volume Detection: Flow integration sampling @ 100Hz Accuracy when Operated in Operating Temperature Range Conditions: Flow +/- from 10% to 5% Max flow rate +/-16L/s Min flow rate +/-0.02L/s Volume Accuracy: Better than +/-3% Maximum Displayed Volume: 10 L
  Maximum Test Duration: 90 seconds Flow Impedance: <0.1kPa/L/s @ 14L/s Complies with ATS/ERS 2005 Printer: Thermal Performance Standards: ATS/ERS 2005 & ISO 26782:2009, ISO 23747:2007 Safety Standards: IEC 60601-1:2005 Medical Safety Standard: Medical Devices Directive 93/42/EEC as amended Designed & Manufactured Under: ISO 13485:2003, FDA 21CFR820, CMDR Communications: USB and Compact Flash
  Download: ALPHA

  Add to wishlist

  Quick view

  Read more
•

  PowerLab (DAQ)

  PowerLab 15T

  PL15T02

  Entry level integrated data recording featuring a dual Bio Amp, an isolated stimulator and 2 analog inputs. Independent ADCs for each channel to keep data perfectly in sync.

  We are the authorised distributor of PowerLab.

  Download:PowerLab Brochure ADInstruments
