Isolated Organ and Tissue 2

This Heated Water Bath is for the most demanding research work.

It has two heaters having 250 watts of combined power.

The temperatur is automatically controlled by a sensitive thermistor

in a metal tube inside the bat to hold the bath water

temperature has stabilized. A magnetic stirrer in the bottom of the

tank slowly circulates the water to ensue uniform temperature.

These heaters are mounted through the front of the tank near the

bottom and extend 100 mm (4 in) into it. The desired temperature of

the Water Bath is set by a dial on the front panel that is graduated

from 15o to 45o C in 5o increments.

Two on/off switches and indicator lamps, one for power and the other

for the magnetic stirrer are on the front panel.

Download:Isolated Organ and Tissue 2

Category: Pharmacology

Reviews (0)

Reviews

There are no reviews yet.

Be the first to review “Isolated Organ and Tissue 2”

Related products

Student Double Tissue Bath

1              Capacity: 5 Liter with decent look

2              Heaters 120 Watts

3              A float switch provides a safety cut off should the water level fall

below the minimum permitted level,

4              Two modes for solution replacement emptying and filling

5              Each tissue chamber has an adjustable gas diffuser for oxygenation and

push toggle on the front of the unit control the filling and emptying of the

tissue chambers via toggle switch.

6              Perspex sheet wall thickness 10mm

7              Magnetic Stirrer for uniform temperature

8              The control system provides an LED display

9              Inner Tissue Bath Standard 25 ml Capacity Qty 2 with each Bath

10           Detachable Stem Tissue Vessel, supplied as standard,

for increased convenience when changing tissue vessels.

(The tissue chamber portion of the tissue vessel can be removed

without disturbing the stem or disconnecting the tubing for the warmed

perfusate and drainage.

11           Inner tissue bath Pyrex Material Graduated 25 ml Capacity

12           O ring provide 2 set

13           Warming Coil Round/Curve flat type

14           Power: 220 Voltages

Downlaod:Student Double Tissue Bath

Read more
Organ Bath Modular-Teaching

AWS provides complete hardware solutions and associated software for isolated tissues studies from simple, manual systems to automated, computer-controlled systems. The AWS Modular Single Chamber Organ Bath was developed to provide a practical and functional design. They are used basically in teaching, where their low demanding maintenance, ruggedness and ease of use guarantee excellent didactic performance. This Modular option consists of a Perspex organ bath with a tissue chamber, three-way stopcock for physiological solution exchange and a fine needle valve for gas regulation. To maintain a constant temperature in the tissue chamber a Thermo regulated Water Pump is available which can be used with up to four Single Chamber Organ Baths at once. All organ baths include tissue holders, transducer holders, Micropostioner and tissue chambers (25 ml volume is supplied standard; 5, 10, or 50 ml volumes are available on request). Optionally, the AWS Modular Organ Baths can be associated with transducers, amplifiers and data output software from several brands. Common configurations use AD Instrument LABCHART or PANLAB PROTOWIN software for data storage and analysis, including Dose/Response.

Download:Organ Bath Modular-Teaching

Read more
Tissue Bath Sets

Research Double Tissue Bath Set

Digital Temperature Control ( Approved Made in Italy)

Temp. Automatically held within 0.1°C.

Control from 15° to 45°C in 0.1° increments.

Large 11.2 L water bath capacity for stable temperature in coils and tissue vessels.

Magnetic stirrer ensures uniform temp.

250 watts of heating power for fast heat-up time.

Warming coils lie flat against sides of tank, leaving center free for procedures.

400 ml capacity flat perfusate warming coils ensure sufficient supply of temp. Controlled Perfusate for lengthy assays.

Detachable stem tissue vessel, for increased convenience when changing tissue vessels (tissue chamber can be removed without disturbing stem or disconnecting tubing for warmed perfusate and drainage.

Basic Double Tissue Bath Sets

Temperature automatically held within 0.5°C.

Dial graduated from 15° to 45°C in 5° increments.

Fixed stem tissue vessels supplied as standard Student. Single Tissue Bath Set

Downlaod:Tissue Bath Sets

Read more
Tissue Organ Bath Components Set

This heavy stand will solidly support the most elaborate assembly. The base measures 150 x 200mm(6 x 8 in), and is finished in tough, durable, smooth white nylon that is easy to keep clean. The base has a brass shoulder to take the upright. This shoulder is located at the center of the base to avoid imbalancing. The upright, which is locked in place with an Allen set crew, is made of stainless steel 12.5 (½ in) in diameter and 720mm (28 in) long. The entire stand weight 5.5kg (12lb) aprox., with base color Black/Red..

Download:Tissue Organ Bath Components Set
